Features/Certifications

  • Approved by ATEX, IECEx
  • CQST (Available on request only)
  • ATEX: Ex d IIC T4~ T6 Gb Ex tb IIIC T135°C~T85°C
  • Zones 1, 2, 21 & 22
  • Conforms to: EN 60079-0:2012 (IEC 60079-0:2011), EN-60079-1:2007 (IEC 60079-1:2007), EN 60079-31:2009 (IEC 60079-31:2008)
  • 360° light output around the vertical axis
  • Dustproof & Weatherproof

Material

Stainless Steel 316 Enclosure
Tempered Glass Lens

Approvals & Conformities

ATEX IECEx
Approvals & Conformities
Categories in this range.

Description

BC125 Series (Stainless Steel)

Explosion Proof Beacon

The BC125 range has been approved for use in potentially explosive atmospheres and very harsh environmental conditions.

Typical applications are Oil and Gas, On-shore and Offshore, Chemical, Petrochemical, Refineries & Marine locations etc.

These beacons have a choice of two types of light source: either Xenon (strobe) with multiple flash rate and power ratings or an LED array with three status type indication options and two power ratings. The design allows for termination inside the enclosure.

The units also have the ability to be fitted with a telephone initiation function and can be used as the second ring output indicator for telephones when installed in very noisy environments.

Part CodeLight SourceVoltage
BC125 AC
LED/Xenon
115/230 AC
BC125 DCLED/Xenon12-48V DC

Xenon Working StatusXenon Flashing
Flash RateSelectable from 60-180 Flashes per Minute
Power Rating5 J (10W) Max10 J (15W) Max15 J (20W) Max20 J (25W) Max
Effective Candela109293395424

LED Working StatusLED - Flashing / Rotating / Static
Flash RateSelectable from 60-120 Flashes per Minute
Rotation RateSelectable from 60-120 Flashes per Minute
Static ModePermanently ON (ie Steady)
Power Rating5 W10 W
Effective Candela128312
MULTIPLYING FACTOR FOR COLOURED LENSES:
Amber x 0.51, Red x 0.15, Blue x 0.12, Green x 0.49, Clear x 1
ENERGY12v Dc24v Dc48v Dc110v Ac220v Ac
5 J460 mA 280 mA140 mA60 mA35 mA
10 J850 mA490 mA250 mA100 mA60 mA
15 J1200 mA700 mA360 mA140 mA80 mA
20 JN/A960 mA480 mA180 mA110 mA
POWER12v Dc24v Dc48v Dc110v Ac220v Ac
5 W530 mA260 mA120 mA80 mA40 mA
10 W1100 mA530 mA240 mA160 mA80 mA
BC125 Explosion Proof Beacons Technical Drawing - Base
BC125 Explosion Proof Beacons Technical Drawing - Side

Brand

Moflash

Moflash Logo

Additional information

Lens Colour

Amber, Blue, Clear, Green, Red

Enclosure Colour

Black, Blue, Red, Yellow

IP Rating

IP 66

Maximum Temperature

+70 °C

Minimum Temperature

-40 °C

Application

Ex Hazardous Area, Industrial, Marine

FPM

FPM 60-120, FPM 60-180

RPM

RPM 60-120

Nominal Supply Voltage

12-48v, 115/230v

Power Rating

Close Proximity Signalling, Long Distance Signalling, Medium Proximity Signalling

Material

Stainless Steel

Zones

Zone 1, Zone 2, Zone 21, Zone 22

Certification

ATEX, CQST (Available on request only), IECEx

Beacon Output

Flashing, Rotating, Static/Steady

Current Type

AC, DC

AC Voltage Frequency

50/60 Hz

Light Source

LED, Xenon
