PB135 Series Explosion Proof Push Button (GRP)

PB135 – Explosion Proof GRP Push Button

Functionality: Self-Reset or Key Reset
Type of fixing: Surface Mounting
Ingress protection: IP66 / IP67
Housing material: GRP (Glass-Reinforced Polyester)
Enclosure colour: Red, Yellow, Blue, Black, Other on Request
Contact rating: 250vAC 11A, 30vDC 6A
Zone ATEX: Gas 1, 2 | Dust 21, 22

IMPORTANT! This product is built to order. Please complete the model configurator in the datasheet and send us the resulting product code so we can provide a quote. Every configuration is confirmed by our team before an order can be placed.

Request a quote

PB135 — Explosion Proof GRP Push Button

The PB135 is a flameproof manual push button for potentially explosive atmospheres. ATEX and IECEx certified for gas and dust zones and SIL2 compliant, it triggers alarms and emergency alerts and interfaces with PLC, ESD or DCS systems.

The Glass-Reinforced Polyester housing with a UV-resistant coating suits corrosive and hazardous areas. Two versions are available — self-reset and key-reset push-pull — with one or two changeover contacts. Optional LED indication, lift flap and line detection extend monitoring and safety. Ambient range is −40°C to +70°C.

Compact 135 × 135 mm flat-format enclosure with top or bottom cable entry. For a 316L stainless steel enclosure, see the PB125.

KEY FEATURES

● Self-reset or key-reset

● 1 or 2 changeover contacts

● Optional LED indication

● Optional lift flap and line detection

● Ex d IIC + H₂ gas group

● IP66/67 rated

● Surface or wall mounting

● ATEX & IECEx certified — Zone Gas 1/2 & Dust 21/22

● SIL2 compliant (IEC 61508 / 61511)

● 11A at 125/250vAC, 6A at 30vDC
